Basic Information
- Manufacturer
- Alteon Networks
- Model
- ACEdirector 2
- ╰ Also known as
-
700111
AD2 - Device Type
- Load Balancer
- Release Year
- 1998
Rack Mounting
- Rackmountable
- Yes
- Rack Units
- 2U
Power
- Power Supply
- Internal
Fixed Interfaces
Data Interfaces
| Qty | Speed | Protocol / Signaling | Interface | Notes |
|---|---|---|---|---|
| 8x | 100 Mbps | Ethernet | RJ-45 (8P8C) | — |
Management Interfaces
| Qty | Type | Interface | Pinout | Notes |
|---|---|---|---|---|
| 1x | Console | DB-9 (DE-9) | — | — |
Software & Docs
| Name | Type | Description |
|---|---|---|
| ACEdirector 2 Installation and User's Guide | Documentation | — |
| AD2/180/180+ Firmware | Firmware | Version 8.0.6.x
TFTP images for ACEdirector 2 and ACEswitch 180/180+ |
Submitted by TheSerialPort on Sept. 19, 2026
