Basic Information
- Manufacturer
- Cisco Systems
- Model
- 2503
- Device Type
- Router
- Release Year
- 1994
Rack Mounting
- Rackmountable
- Yes
- Rack Units
- 1U
Power
- Power Supply
- Internal
Fixed Interfaces
Data Interfaces
| Qty | Speed | Protocol / Signaling | Interface | Notes |
|---|---|---|---|---|
| 1x | 128 kbps | ISDN BRI (S/T) | RJ-45 (8P8C) | — |
| 1x | 10 Mbps | Ethernet | DA-15 | — |
| 2x | 2.048 Mbps | TIA-232 (RS-232)TIA-449 (RS-449)TIA-530 (RS-530)V.35X.21 | Proprietary | — |
Management Interfaces
| Qty | Type | Interface | Pinout | Notes |
|---|---|---|---|---|
| 1x | Console | RJ-45 (8P8C) | — | — |
| 1x | Remote | RJ-45 (8P8C) | — | — |
