SynOptics Communications Model 2510 Retiming Concentrator

Hub

Model 2510 Retiming Concentrator
Model 2510 Retiming Concentrator
Model 2510 Retiming Concentrator
Model 2510 Retiming Concentrator
Model 2510 Retiming Concentrator

Basic Information

Manufacturer
SynOptics Communications
Model
Model 2510 Retiming Concentrator
╰ Also known as
960-029
Device Type
Hub
Release Year
1988

Rack Mounting

Rackmountable
Yes
Rack Units
1U

Power

Power Supply
External

Fixed Interfaces

Data Interfaces

Qty Speed Protocol / Signaling Interface Notes
8x 10 Mbps LattisNet RJ-45 (8P8C)
—
1x 10 Mbps LattisNet RJ-45 (8P8C)
Crossover port

Notes

Feb 20, 2026 6:41 PM · ben

Power connector pinout:

-------------------------------------------
| PIN | FUNCTION          | SPECIFICATION |
|-----|-------------------|---------------|
| 1   | SIGNAL GROUND     |               |
| 2   | COMMON            |               |
| 3   | + 5VDC            | 2A            |
| 4   | - 12 VDC          | 0.5A          |
| 5   | KEYED / N.C.      |               |
| 6   | + 12 VDC          | 0.5A          |
-------------------------------------------
